With single/ Double / Triple Outreach Arm
The application place can be Street / Road Lighting, Highway Lighting, Commercial Areas Lighting, Seaport Lighting, AirPort Lighting, etc
The wall thickness can be 2~30mm OR as request
The shape can be Conical, Round, Polygonal (Octagonal, Dodecagonal)
Can be powder coated or painted according to clients’ request
16m Once forming without joint
| Take H 6.5m + L 6m as an example: | |
| Lamp pole
Steel:Q235A Diameter of upright rod: 220-280mm Thickness of upright rod: 5mm Diameter of horizontal rod: 100-200mm Thickness of horizontal rod: 4mm Diameter of bottom flange: 550mm Thickness of bottom flange: 18mm Connecting flange: 300*300mm Welding mode: Automatic submerged-arc welding Anti-corrosion treatment: Pickling + internal and external hot galvanization + passivation + electrostatic plastic spraying Thickness of zinc coating: ≥86um Thickness of sprayed plastic coating: ≧100 um Appearance: Smooth surface, hardness ≧ 2H |
Traffic light:
Form: Combination of red, green, and yellow Housing: Aluminum alloy or PC Dimensions: 1050*350mm Light source: Full screen or arrow Diameter of single lamp: 300、400mm Power: 5-24W Voltage: 220V Weight: About 10KG Sign: Customization: Yes Material: Aluminum-alloy plate + aluminum slot Category of reflective coating: Super High Level, High Level, Diamond Level Background color: Yellow, blue, or white Thickness: 1.2、1.5、2、3mm |
| Remarks:
The above are only conventional parameters. Customization is available according to user requirements. |
|
| Price description:
Since street lamps are non-standard products that can be customized with different heights, power, etc. according to user requirements, no factory has a fixed price list. Please first choose the style, and tell us your simple requirements, or tell us your use environment; then we will recommend relevant style and parameters for you and offer you a quote. For specific price consultation, please contact us. |
|
